Configuring Workload identity federation between GCP and AWS EKS

• August 4, 2022

Workload identity federation is the process of impersonating an identity in one cloud provider from the other without long lived keys. In this blog post we will walk through how to setup federation between a workload running on AWS EKS (In this case CloudQuery so you can also fetch configuration from your GCP accounts) to GCP.

Step 1: Create AWS Infrastructure for CloudQuery on EKS #

In this guide, we run CloudQuery on AWS EKS with the official CloudQuery Helm Charts.

IAM Roles for CloudQuery on EKS #

For EKS, IAM setup may require an Amazon EKS cluster IAM role and an Amazon EKS node IAM role. Refer to AWS documentation for more information on IAM setup and best practices for securing IAM for EKS Clusters.

Step 2: Enable Additional GCP Services #

The Security Token Service API and the IAM Service Account Credentials API need to be enabled in our GCP project.

gcloud services enable sts.googleapis.com
gcloud services enable iamcredentials.googleapis.com

Step 3: Create GCP Service Account #

Now we need to create the GCP Service Account which CloudQuery will authenticate with in order to fetch the GCP resources.

gcloud iam service-accounts create cq-fetcher \
    --description="CloudQuery fetcher which runs on AWS." \
    --display-name="cq-fetcher"

We need to ensure that the new Service Account has the appropriate permissions to view the desired projects in GCP.

Step 4: Create GCP Workload Identity Pool #

Next, we need to create the GCP Workload Identity Pool.

gcloud iam workload-identity-pools create cq-aws-pool \
    --description="Workload Identity Pool for CloudQuery on AWS." \
    --display-name="CloudQuery AWS Pool" \
    --location="global"

Step 5: Create Workload Identity Provider #

After creating the GCP Workload Identity Pool we need to create the Workload Identity Provider. This example does not cover how to harden the Identity Provider, which can be achieved by passing the --attribute-condition flag.

gcloud iam workload-identity-pools \
    providers create-aws cq-aws-provider  \
    --account-id=123456789012 \
    --description="Workload Identity Provider for CloudQuery on AWS." \
    --display-name="CloudQuery AWS Provider" \
    --location="global" \
    --workload-identity-pool="cq-aws-pool"

Step 6: Bind GCP Service Account Impersonation #

Now, we will create an IAM policy binding.

The below command allows all identities from our pool to impersonate the GCP Service Account we created earlier by binding the IAM role roles/iam.workloadIdentityUser to the GCP service account. Replace the number in the -member flag with the GCP project number.

gcloud iam service-accounts add-iam-policy-binding \
    [email protected] \
    --member "principalSet://iam.googleapis.com/projects/123456789012/locations/global/workloadIdentityPools/cq-aws-pool/*" \
    --role "roles/iam.workloadIdentityUser"

Please consider adjusting the -member flag for additional security with GCP service account impersonation. More granular options include options such as a single identity, all identities in a group, or all identities with a specific attribute value. More information can be found in the Service account impersonation section of Google Cloud Docs. We recommend using granular scoping for service account impersonation.

An example of using a single identity in the pool could look like the following command. Additional configuration may be required for attribute mapping and conditions. Information on defining attribute mapping can be found here.

gcloud iam service-accounts add-iam-policy-binding \
    [email protected] \
    --member "principalSet://iam.googleapis.com/projects/123456789012/locations/global/workloadIdentityPools/cq-aws-pool/attribute.aws_role/CQ_AWS_Role" \
    --role "roles/iam.workloadIdentityUser"

Step 7: Download Client library Config #

The Client library Config needs to be downloaded, this can be achieved by navigating to the Workload Identity Pool and selecting the CONNECTED SERVICE ACCOUNTS Tab on the right side. The Client library Config can be obtained from there. The file does NOT contain sensitive information.

Step 8: Configure CloudQuery #

The downloaded Client library config needs to be uploaded to our Kubernetes as a config map.

kubectl -ncloudquery create configmap \
    cq-gcp-application-default-credentials \
    --from-file=./application_default_credentials.json

Now we just need to inject the Client library config into our Pod with the help of a volume mount. This can be achieved by adding those values into the values.yaml of the Helm Chart.

volumes:
  - name: gcp
    configMap:
      name: cq-application-default-credentials
      items:
        - key: application_default_credentials.json
          path: application_default_credentials.json
volumeMounts:
  - mountPath: /root/.config/gcloud/
    name: gcp

Conclusion #

That’s it! Now you can ingest your configuration across clouds into a single PostgreSQL database, visualise with your favourite BI tool and build your own asset inventory, CSPM, search and any other use-case you have in mind!

Ready to get started with CloudQuery? You can try out CloudQuery locally with our quick start guide or explore the CloudQuery Platform (currently in beta) for a more scalable solution.

Want help getting started? Join the CloudQuery community to connect with other users and experts, or message our team directly here if you have any questions.
