tutorial

Building a Multi-Cloud Asset Inventory for Google Cloud Platform (GCP) and AWS with CloudQuery

• October 25, 2024

Managing assets across multiple cloud providers like AWS and GCP can be challenging, especially when trying to keep track of everything in one place. What if you could centralize this data and make it easy to query? That's exactly what we'll be doing in this live coding session. Using CloudQuery, we'll demonstrate how to pull cloud asset data from AWS and GCP and store it in a PostgreSQL database for easy access and analysis.

We'll cover the entire process—from configuring CloudQuery for multi-cloud data ingestion to running queries that help you manage and secure your cloud assets.

If you want to follow along with a video version of this post, you can check that out here:

Key Takeaways #

How to configure CloudQuery to pull asset data from both AWS and GCP.
Setting up PostgreSQL as the backend to store and query cloud asset information.
An introduction to ETL (Extract, Transform, Load) processes to bring in cloud data.
Best practices for querying and managing cloud resources in a multi-cloud environment.

Why Build a Multi-Cloud Asset Inventory? #

As companies increasingly rely on multiple cloud providers, keeping track of resources becomes crucial for operations and security. Cloud assets like storage buckets, virtual machines, and security policies often span multiple clouds. Without centralized oversight, it’s easy to lose track of important assets, leading to security vulnerabilities or inefficiencies.

Using CloudQuery, we can easily pull this data into a central database and ensure everything is visible from one location. This simplifies tracking down assets, audits their configurations, and ensures they comply with your security policies.

Overview of the Process #

Here’s what we'll be doing:

Install and configure CloudQuery: Set up the tool that pulls in data from AWS and GCP.
Set up PostgreSQL: Store your cloud data in a robust, queryable database.
Sync AWS and GCP data: Import assets from both clouds into PostgreSQL.
Run example queries: Retrieve and analyze your cloud assets.

CloudQuery supports any source integration with any destination. You can find more information about the available integrations in the CloudQuery Hub.

Let’s dive in.

—

Step 0: Prerequisites #

Before jumping into the demo, you’ll need a few prerequisites to ensure everything runs smoothly. These setup steps will prepare your environment to sync cloud data from AWS and GCP into PostgreSQL.

1. AWS Access #

You will need AWS credentials to pull cloud asset data from AWS. Ensure you have updated access keys (AWS_ACCESS_KEY_ID, AWS_SECRET_ACCESS_KEY, and AWS_SESSION_TOKEN). These keys allow CloudQuery to authenticate with AWS and retrieve data.

Export your credentials to the environment:

export AWS_ACCESS=YOUR_AWS_ACCESS_KEY
export AWS_SECRET=YOUR_AWS_SECRET_ACCESS_KEY
export AWS_SESSION=YOUR_AWS_SESSION

3. GCP Authentication #

To access GCP assets, you’ll need to authenticate using the GCP CLI. First, install the Google Cloud SDK if you don’t already have it. After installation, authenticate your GCP account using the following command:

4. Docker #

We’ll be using Docker to run a PostgreSQL container where cloud assets from AWS and GCP will be stored. Make sure Docker is installed and running on your local machine before proceeding with the demo.

Step 1: Installing CloudQuery #

The first step is to install CloudQuery, which will act as the engine for pulling in cloud asset data. CloudQuery is open-source, which means it’s free to use and easy to extend if needed. It supports a wide range of cloud providers, and in our case, we'll focus on AWS and GCP.

To get started, install CloudQuery using Homebrew:

brew install cloudquery/tap/cloudquery

After the installation, you’ll need to log in using your CloudQuery credentials:

cloudquery login

This login gives CloudQuery access to your cloud accounts and allows it to pull in asset data. Once logged in, you’re ready to start pulling in cloud data.

Step 2: Setting Up PostgreSQL #

Now, we need a place to store all this data. We’ll use PostgreSQL, a powerful (and popular) open-source database that works great for storing structured data like cloud assets.

If you don’t already have a PostgreSQL database set up, you can easily run one in a Docker container. This is a fast way to get things running without much setup. Here’s the command to start PostgreSQL in Docker:

docker run --name postgres_container \
--restart unless-stopped \
--env POSTGRES_USER=postgres \
--env POSTGRES_PASSWORD=postgres \
--env POSTGRES_DB=asset_inventory \
--publish 5432:5432 \
--volume pgdata:/var/lib/postgresql/data \
postgres

This command will launch a PostgreSQL pre-configured container to store your cloud assets. The credentials are set to Postgres for both the username and password, but you can adjust this as needed.

Step 3: Configuring CloudQuery for AWS #

Next, we’ll configure CloudQuery to pull data from AWS and sync it to PostgreSQL. CloudQuery works by defining sources (like AWS) and destinations (like PostgreSQL). It then automates the process of syncing data between them.

Start by initializing a CloudQuery project for AWS:

cloudquery init --source=aws --destination=postgresql

This command sets up the necessary configurations for pulling data from AWS and storing it in PostgreSQL. The configurations are defined in a YAML file that CloudQuery generates for you. In our case, we’re targeting AWS S3 buckets, but CloudQuery supports many other AWS resources like EC2 instances, security groups, and more.

Now, let’s take a quick look at how we can define this process. Here’s a basic example of what the configuration file looks like (aws_to_postgresql.yaml):

kind: source
spec:
   # Source spec section
   name: aws
   path: cloudquery/aws
   registry: cloudquery
   version: "v28.1.0"
   tables: ["aws_s3_buckets"]
   destinations: ["postgresql"]
---
kind: destination
spec:
   name: "postgresql"
   path: "cloudquery/postgresql"
   registry: "cloudquery"
   version: "v8.6.4"
   write_mode: "overwrite-delete-stale"

This file tells CloudQuery to pull in AWS S3 buckets and store them in the PostgreSQL database running on localhost.

Step 4: Syncing Data from AWS #

With our configuration in place, we’re ready to start syncing data.

To sync AWS data into PostgreSQL, run the following command:

cloudquery sync aws_to_postgresql.yaml

This will kick off the process of pulling S3 bucket data from AWS and storing it in your PostgreSQL database.

Example 1: List AWS S3 Buckets #

Now that we have data in PostgreSQL, let’s run a simple query to list the first 10 S3 buckets:

docker exec -it postgres_container psql -U postgres -d asset_inventory -c 'SELECT name, region FROM aws_s3_buckets LIMIT 10;'

Example 2: Identify Public Buckets #

Let's get to something more interesting, since security is always a top concern, let’s write a query to identify any S3 buckets that have public access policies enabled:

docker exec -it postgres_container psql -U postgres -d asset_inventory -c "
SELECT
 name, arn, policy_status
FROM
 aws_s3_buckets
WHERE
 policy_status->>'isPublic' = 'true';
"

This query will show you which buckets are publicly accessible, which is a critical piece of information for platform security engineers.

Step 5: Configuring CloudQuery for GCP #

Once we have AWS data stored, we can repeat this process for GCP. Initialize CloudQuery for GCP with:

cloudquery init --source=gcp --destination=postgresql

Then, sync GCP data in the same way:

cloudquery sync gcp_to_postgresql.yaml

Now you’ll have cloud asset data from both AWS and GCP stored in PostgreSQL.

Step 6: Querying Your Cloud Assets #

Once your cloud assets are stored in PostgreSQL, you can query them just like any other database. Let’s look at a few useful queries.

Example 3: Unified View Across AWS and GCP #

Now, let’s combine data from both AWS and GCP to get a unified view of our cloud storage buckets:

docker exec -it postgres_container psql -U postgres -d asset_inventory -c "
SELECT
 name AS bucket_name,
 creation_date AS created_date,
 region AS location,
 'AWS' AS cloud_provider
FROM
 aws_s3_buckets

UNION ALL

SELECT
 name AS bucket_name,
 created AS created_date,
 location AS location,
 'GCP' AS cloud_provider
FROM
 gcp_storage_buckets
ORDER BY
 created_date DESC;
"

This query lists all buckets from both AWS and GCP, showing their creation dates, locations, and which cloud provider they belong to. It’s a simple way to track assets across clouds.

Summary #

Building a multi-cloud asset inventory allows you to centralize data from multiple providers like AWS and GCP, giving you better visibility and control over your cloud infrastructure. With CloudQuery and PostgreSQL, you can easily pull in data, store it, and query it all in one place.

By following this guide, you’ll have a functional asset inventory, and you can start running queries to manage and secure your cloud resources more effectively.

Ready to build your own cloud asset inventory? You can download and use CloudQuery and follow along with our quick start guide, or explore CloudQuery Cloud for a more scalable solution.

Want help getting started? Join the CloudQuery community to connect with other users and experts, or message our team directly here if you have any questions.

Additional Resources #

Written by Joe Karlsson

Joe Karlsson (He/They) is an Engineer turned Developer Advocate (and massive nerd). Joe empowers developers to think creatively when building applications, through demos, blogs, videos, or whatever else developers need.
